Ziewnic hybrid solar inverter

Ziewnic Marvel 5g (7KVA) PV8500 Inverter Features

• True European 5th-Generation Design
  The first of its kind in Pakistan—engineered in Europe for enhanced quality and performance.

• Single-Phase (Upgradeable to Three-Phase via Parallel Installation)
  Ideal for both residential use and scalable commercial deployment when multiple units are paralleled.

• 100% Pure Sine Wave Output with Perfect Power Factor (PF = 1.0)
  Clean and stable AC output, safeguarding sensitive electronics.

• Dual 8.5 kW MPPT Solar Chargers with High Capacity (160 A)
  Ensures efficient energy harvesting even in variable sunlight conditions.

• Wide PV Voltage Compatibility (120–500 V DC) & 36 A Max PV Input Current
  Compatible with diverse solar panel setups for optimal flexibility.

• Multimode Operation – On-Grid, Off-Grid & Hybrid
  Versatile power modes that adapt to battery availability and grid connection.

• Zero Export & Net Metering Capability with 100% Reverse Grid Flow
  Enables energy harvesting without unauthorized feed-in, while supporting full grid credit when possible.

• Zero Transfer Time & 98% Real-Time Load Sharing
  Ensures uninterrupted power during transitions with high sharing efficiency.

• Built-in Battery Equalization and BMS
  Extends battery longevity by balancing cells—compatible with Li-ion and lead-acid types.

• Smart Multi-schedule Power Management
  Enables energy usage optimization through programmable schedules.

• Comprehensive Monitoring and Communication
  Offers real-time control and monitoring via built-in Wi-Fi (10 m range), and connectivity through RS232, RS485, USB, and CAN ports.

• Touch Color LCD with Smart & Anti-Dust Design
  Advanced display for easy configuration with protective conformal coating for harsh environments.

• High Surge & Overload Protection
  Manages peaks with 2× rated power surge for 5 seconds and safely handles 150% overload.

• Parallel Capability up to 12 Units
  Ideal for scalable three-phase configurations or increased power needs.

• Robust Construction with Conformal Coating
  Dust- and humidity-resistant design ensures durability and reliability in tough conditions.

• European Design, Taiwanese Build Quality
  Combines high-performance engineering with meticulous manufacturing standards.

• Specifications at a Glance

  • Power Output: 7 kVA / 6.5 kW

  • System Voltage: 48 V

  • Charge Controller: Dual MPPT, 8.5 kW (160 A)

  • Weight: ~13.5–18 kg (depending on model)

  • IP Rating: IP21 (indoor use)
